D.A.W.N. - Digital Assistant for Wearable Neutronics (AI Assistant)

These instructions are currently in the "do this" phase. This "works for me" and I welcome your feedback.

DAWN AI Assistant

Application Notes

  • OpenAI API - An OpenAI API key is required for the current implementation of the cloud AI using OpenAI. Getting an API key is currently beyond the scope of this document. Please see OpenAI's documentation for details.
  • If you do not wish to use cloud AI or you only want local command support, there is a flag to disable it.

Installation Notes (Required Software)

System Packages

  1. sudo apt install libssl-dev

Cmake 3.27.1

  1. tar xvf cmake-3.27.1.tar.gz
  2. cd cmake-3.27.1
  3. ./configure --system-curl
  4. make -j8
  5. sudo make install

spdlog

  1. git clone https://github.com/gabime/spdlog.git
  2. cd spdlog
  3. mkdir build && cd build
  4. cmake .. && make -j8
  5. sudo make install

espeak-ng (git)

Before we begin: sudo apt purge espeak-ng-data libespeak-ng1 speech-dispatcher-espeak-ng

  1. git clone https://github.com/rhasspy/espeak-ng.git
  2. cd espeak-ng
  3. ./autogen.sh
  4. ./configure --prefix=/usr
  5. make -j8 src/espeak-ng src/speak-ng
  6. make
  7. sudo make LIBDIR=/usr/lib/aarch64-linux-gnu install

Onnxruntime (git)

  1. git clone --recursive https://github.com/microsoft/onnxruntime
  2. cd onnxruntime
  3. ./build.sh --config Release --use_cuda --cuda_home /usr/local/cuda-12.2 --cudnn_home /usr/lib/aarch64-linux-gnu --build_shared_lib --skip_tests --parallel $(nproc) --arm
  4. cd build/Linux/Release/
  5. sudo make install

piper-phonemize (git)

  1. git clone https://github.com/rhasspy/piper-phonemize.git
  2. cd piper-phonemize
    1. cd src && cp ../../onnxruntime/include/onnxruntime/core/session/*.h .
    2. cd ..
  3. mkdir build && cd build
  4. cmake ..
  5. make
  6. sudo make install

piper (git)

  1. git clone https://github.com/rhasspy/piper.git
  2. cd piper
  3. make - You'll get some errors on copies at the end but it builds.

kaldi (git) (This is a REALLY long build process!)

  1. sudo apt-get install sox subversion
  2. sudo git clone -b vosk --single-branch --depth=1 https://github.com/alphacep/kaldi /opt/kaldi
  3. sudo chown -R $USER /opt/kaldi
  4. cd /opt/kaldi/tools
  5. Edit Makefile. Remove -msse -msse2 from openfst_add_CXXFLAGS
  6. make openfst cub (Note: -j# doesn't seem to work here.) LONG BUILD
  7. ./extras/install_openblas_clapack.sh
  8. cd ../src
  9. ./configure --mathlib=OPENBLAS_CLAPACK --shared
  10. make -j 10 online2 lm rnnlm
  11. cd ../..
  12. sudo git clone https://github.com/alphacep/vosk-api --depth=1
  13. sudo chown -R $USER vosk-api
  14. cd vosk-api/src
  15. KALDI_ROOT=/opt/kaldi make -j8
  16. cd ../c
  17. Edit Makefile. Add the following to LDFLAGS: $(shell pkg-config --libs cuda-12.2 cudart-12.2) -lcusparse -lcublas -lcusolver -lcurand
    1. make
  18. Choose a model:
    1. wget https://alphacephei.com/vosk/models/vosk-model-small-en-us-0.15.zip
    2. wget https://alphacephei.com/vosk/models/vosk-model-en-us-0.22.zip
  19. unzip vosk-model-en-us-0.22.zip
  20. ln -s vosk-model-en-us-0.22 model
  21. cp ../python/example/test.wav .
  22. ./test_vosk

Copy some files over for compiling

  1. cp -r vosk-model-en-us-0.22 SOURCE_DIR
  2. cp ../src/vosk_api.h ../src/libvosk.so SOURCE_DIR

Build DAWN

  1. mkdir build
  2. cd build
  3. cmake ..
  4. make

DAWN Application Configuration Documentation (commands_config_nuevo.json)

The DAWN application utilizes a sophisticated configuration file designed to enhance interactivity through local voice commands and actions. This documentation outlines the structure and purpose of each section within the file, focusing on how actions are defined and linked to specific devices, including audio settings customization.

Types and Actions

{
  "types": {
     "boolean": {
        "actions": {
           "enable": {
              "action_words": ["enable %device_name%", "turn on %device_name%", "switch on %device_name%", "show %device_name%", "display %device_name%", "open %device_name%", "start %device_name%"],
              "action_command": "{\"device\": \"%device_name%\", \"action\": \"enable\"}"
           },
           "disable": {
              "action_words": ["disable %device_name%", "turn off %device_name%", "switch off %device_name%", "hide %device_name%", "close %device_name%", "stop %device_name%"],
              "action_command": "{\"device\": \"%device_name%\", \"action\": \"disable\"}"
           }
        }
     }
  }
}
  • types: Represent the different categories of settings that can be adjusted or monitored within the DAWN system. These include boolean for toggle settings, analog for value-based adjustments, getter for retrieving information, and music for controlling audio playback.
  • actions: Defined within each type, actions describe what operations can be performed. Each action has associated action_words, which are the voice commands recognized by DAWN to trigger the action, and an action_command, the MQTT JSON string sent to the target device to execute the action.

Devices

This section lists the various devices controlled by DAWN, detailing how voice commands translate into specific actions for each device:

  • type: Links the device to one of the defined types (e.g., boolean, analog), dictating the nature of its control.
  • aliases: Alternative names or phrases that can also refer to the device, enhancing the system's ability to recognize voice commands intended for it.
  • topic: The MQTT topic the device publishes to, ensuring that commands are accurately directed in the network.

Audio Devices

Specific to the configuration of audio input and output devices, this section allows DAWN to correctly setup and utilize audio hardware. This is independent of the rest of the configuration.

Each audio device is categorized by its function (e.g., microphone, headphones, speakers), with detailed configurations for effective operation.

  • type: Identifies the role of the audio device within the system (e.g., audio capture device for microphones).
  • aliases: Provides additional identification terms for each device, facilitating user interaction.
  • device: The system identifier for the hardware, used by DAWN to apply the correct settings.
  "audio devices": {
     "microphone": {
        "type": "audio capture device",
        "aliases": ["mic", "helmet mic", "audio input device"],
        "device": "alsa_input.usb-Creative_Technology_Ltd_Sound_Blaster_Play__3_00128226-00.analog-stereo"
     },
     "headphones": {
        "type": "audio playback device",
        "aliases": ["helmet"],
        "device": "combined"
     },
     "speakers": {
        "type": "audio playback device",
        "aliases": ["speaker", "loud speakers", "loud speaker", "chest speaker"],
        "device": "combined"
     }
  }

Hints:

  • pactl list short sinks
  • pactl list short sources
  • Set your audio devices: commands_config_nuevo.json

Run DAWN

  1. ./dawn

Credits

Initial adaptation from the piper project: https://github.com/rhasspy/piper

Piper and the language models are covered under the MIT license. Vosk Licensed under the Apache License, Version 2.0.
